Description
Smart AT-56S IR Illuminator Range/Beam Angle Options
See the chart below to select the light angle coverage option that matches the range needed for your application.
*Article: About Elliptical Light Beam Angles
Smart 56S IR Illuminator 850nm
$1,291.00 MSRP
The Smart AT-56S Long Range IR Illuminator has Input/Output ports that can be used to connect to motion sensors, camera or other I/O port devices to turn light On/Off based on preset conditions. For easy integration, an automatic DAY/NIGHT sensor turns IR ON/OFF, based upon lighting conditions. Smart series IR Illuminators are rugged, vandal resistant, Outdoor IP67 Rated (weatherproof) and have AXTON’s exclusive lifetime warranty.
- Wavelength – 850nm Infrared
- Energy Efficient – Advanced LED Technology
- Outdoor IP67 Rated (waterproof)
- Illumination Range: 1,200ft 10˚/ 270ft 90˚
- Six Beam Angle/Coverage Options:
150˚, 90˚ (60˚x 30˚ elliptical*) 30˚ (20˚x10˚) or 10˚ See Range chart below. - Power Consumption – 56 Watts
- Input Voltage – 24-36 VDC or 24 VAC
- I/O Port Sync with Motion Sensors, Camera I/O Port Devices
- Automatic Day/Night Sensor
- Rugged Construction: All Metal Housing/Bracket, Polycarbonate Face/Lens
- Lifetime Warranty, Designed and Manufactured in the USA
- Pan/Tilt U Bracket Included
Mounting adapter available separately see: Wall, Corner or Pole Panning Mounts.
AT-56S.56S286030, AT-56S.56S2890, AT-56S.56S2810, AT-56S.56S282010, AT-56S.56S2830, AT-56S.56S28150, AT-56S, axton LED Light
Specifications
| Smart 56S Specifications | |
| Wavelength | 850nm Infrared |
| Input Voltage | 24-36 VDC or 24 VAC |
| Power Consumption | 56 Watts |
| Features | Input/Output Ports Day/Night Sensor |
| Operating Temperature | -58° to 140°F / -50° to 60°C |
| Dimensions | 6.25” x 3.5” x 9.25”/ 159 x 89 x 235mm |
| Weight | 5 lbs / 2.2kg. |
| Environmental | Outdoor IP67 Rated |
| Mounting | Pan/Tilt U-bracket |
(Wavelength Option: 730nm Deep Red, contact us for details)
Part Numbers
| ANGLE | DESCRIPTION | PART NUMBER |
| 10˚ | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 10° | AT-56S.56S2810 |
| 20°x10° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 20°x10° | AT-56S.56S282010 |
| 30° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 30° | AT-56S.56S2830 |
| 60°x30° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 60°x30° | AT-56S.56S286030 |
| 90˚ | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 90° | AT-56S.56S2890 |
| 150° | 56W, Smart Series, Day/Night Sensor, I/O Ports, 24-36VDC or 24VAC Input, 850nm, 150° | AT-56S.56S28150 |
