MegaPixel AT-25E PoE IR Illuminator – Beam Angle Options & Ranges
What are elliptical beam angles? About Elliptical Light Beam Angles
Read More: How to Choose Lighting for a Security Camera
MegaPixel 25E PoE IR Illuminator
$882.00 MSRP
The MegaPixel AT-25E, PoE+ Powered IR Illuminator, allows seamless and precise integration via input output (I/O) ports. Sync with a camera or any other system device with I/O capability. For easy integration, an automatic built-in DAY/NIGHT sensor turns IR ON/OFF, based upon lighting conditions. Request a Free DEMO (USA Only)
- Light Wavelength – “invisible” 850nm Infrared Light
- High Efficiency LED IR Illuminator
Over 100% More Range per Watt than comparable U.S. IR illuminators - Range: up to 800ft Angle Options:
150˚, 90˚ (60˚x 30˚ elliptical) 30˚ (20˚x10˚) or 10˚ - Outdoor IP67 Rated (weatherproof)
- Rugged Construction, Impact Rating: IK10 (IEC 62262) Vandal-resistant
- I/O Port Control for Camera & Sensor Sync
- Built-in Light sensor for Auto On/Off
- Power Consumption – 25 Watts
- Input Voltage – PoE+ (or PoE++)
- Lifetime Warranty, Designed and Manufactured in the USA
- Pan/Tilt U Bracket Included
Mounting adapter available separately see: Wall, Corner or Pole Panning Mounts.
PoE Set-up Basics: PoE Powered Lighting Set-Up.
Pricing may vary. Sign-in to view preferred pricing.
For project or bulk orders, please contact us or a distributor for pricing.
Specifications
MegaPixel AT-25E-S Specifications | IK10 (IEC 62262) |
| Wavelength | 850nm Infrared |
| Input Power | PoE+ 802.3at, or PoE++ (24 VDC Auxilliary Available) |
| Power Consumption | 25 Watts |
| Features | Input/Output Ports Day/Night Sensor |
| Impact Rating: | IK10 (IEC 62262) |
| Operating Temperature | -58°to140°F / -50° to 60°C |
| Dimensions | 5.25” x 3” x 7.25” /133 x 76 x 184mm |
| Weight | 3 lbs /1.3kg |
| Environmental | Outdoor IP67 Rated |
| Mounting | Pan/Tilt U-bracket |
(Wavelength Option: 730nm Deep Red, contact us for details)
Setup
Quick Setup Guide PoE
Setup Guide PoE PDF
PoE Connection Diagram
Example Only – There are many possible PoE connection configurations.
PoE Connection Diagram
Example Only – There are many possible PoE connection configurations.
Part Numbers
| ANGLE | DESCRIPTION | PART NUMBER |
| 10˚ | 24W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE+ Input, 850nm, 10° | AT-25E-S.25ES3810 |
| 20°x10° | 24W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE+ Input, 850nm, 20˚ x 10° | AT-25E-S.25ES382010 |
| 30° | 24W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE+ Input, 850nm, 30° | AT-25E-S.25ES3830 |
| 60°x30° | 24W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE+ Input, 850nm, 60° x 30˚ | AT-25E-S.25ES386030 |
| 90˚ | 24W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE+ Input, 850nm, 90° | AT-25E-S.25ES3890 |
| 150° | 24W, MegaPixel Series, Day/Night Sensor, I/O Ports, PoE+ Input, 850nm, 150° | AT-25E-S.25ES38150 |
