Description
Helios 25Y Solar IR Illuminator – Range & Beam Angle Options
See the chart below to select the IR light illumination angle option that matches the range needed for your site.
*Article: About Elliptical Light Beam Angles
Helios 25Y Solar IR Illuminator
$882.00 MSRP
The AXTON HELIOS 25Y IR Illuminator is designed for off-grid and mobile security camera systems. Operating directly from an external 9–28 VDC solar or battery power system, it features I/O ports for integration and control with cameras, motion sensors, and other system devices. A built-in DAY/NIGHT sensor provides automatic ON/OFF operation. Its rugged, vandal-resistant housing is outdoor IP67 rated for reliable all-weather use.
- Light Wavelength – “invisible” 850nm Infrared Light
- High Efficiency LED IR Illuminator
Over 100% More Range per Watt than comparable U.S. IR illuminators - Range: up to 800ft Angle Options:
150˚, 90˚ (60˚x 30˚ elliptical) 30˚ (20˚x10˚) or 10˚ - Voltage Input: 9 to 28 VDC | Power Consumption – 25 Watts
For use with an external solar or battery power system. - Outdoor IP67 Rated (weatherproof)
- I/O Port Control for Camera & Sensor Sync
- Built in light sensor for auto On/Off
- Impact Rating: IK10 (IEC 62262) Vandal-resistant
- Lifetime Warranty, Designed and Manufactured in the USA
- Pan/Tilt U Bracket Included Mounting adapter available separately see: Wall, Corner or Pole Panning Mounts.
Solar Power: Solar Lighting Set-Up Basics
Pricing may vary. Sign-in to view preferred pricing.
For project or bulk orders, please contact us or a distributor for pricing.
Specifications
Helios 25Y Specifications | |
| Wavelength | 850nm Infrared |
| Input Voltage | 9 to 28 VDC |
| Power Consumption | 25 Watts |
| Features | Input/Output Ports Day/Night Sensor |
| Operating Temperature | -58°to140°F / -50° to 60°C |
| Dimensions | 5.25" x 3" x 7.25"/ 133 x 76 x 184mm |
| Weight | 3 lbs /1.3kg |
| Impact Rating: | IK10 (IEC 62262) |
| Environmental | Outdoor IP67 Rated |
| Mounting | Pan/Tilt U bracket |
Part Numbers
Helios AT-25Y-S Part Numbers | ||
ANGLE | DESCRIPTION | PART NUMBER |
| 10˚ | 25W, Helios Series, Day/Night Sensor, I/O Ports, 9 to 28 VDC Input, 850nm IR, 10° | AT-25Y-S.25YS1810 |
| 20˚ x 10˚ | 25W, Helios Series, Day/Night Sensor, I/O Ports, 9 to 28 VDC Input, 850nm IR, 20°x10° | AT-25Y-S.25YS182010 |
| 30° | 25W, Helios Series, Day/Night Sensor, I/O Ports, 9 to 28 VDC Input, 850nm IR, 30° | AT-25Y-S.25YS1830 |
| 60° x 30˚ | 25W, Helios Series, Day/Night Sensor, I/O Ports, 9 to 28 VDC Input, 850nm IR, 60°x30° | AT-25Y-S.25YS186030 |
| 90˚ | 25W, Helios Series, Day/Night Sensor, I/O Ports, 9 to 28 VDC Input, 850nm IR, 90° | AT-25Y-S.25YS1890 |
| 150° | 25W, Helios Series, Day/Night Sensor, I/O Ports, 9 to 28 VDC Input, 850nm IR, 150° | AT-25Y-S.25YS18150 |
